Kärcher Puzzi 8/1 C User Manual

– 2
Illustration
1 Connect spray/suction hose to the el-
bow,
Connect spray/suction hose to the ap-
pliance
2 Prepare cleaning solution,
Fill up the fresh water tank
3 Select operating mode
4 Cleaning
5 Empty the fresh water tank
6 Empty wastewater container
7 Fill fresh water tank (without detergent),
Flush appliance
8 Clean lint trap,
Clean fresh water sieve
9 Allow appliance to dry
Illustration
1 Manual nozzle for upholstery cleaning
2 Hook for spray/suction hose
3 Holder for accessories
4 Power cord
5 Quick start instructions
6 Switch for spraying
7 Switch for vacuuming
8 Fresh water sieve
9 Casing
10 Nameplate
11 Steering roller
12 Spray hose connection
13 Suction hose connection
14 Nozzle mouth piece
15 Union joint
16 Cover
17 Fresh water tank
18 Carrying handle of the appliance
19 Bender
20 Lever on the manifold
21 Spray hose
22 Suction hose
23 Spray/suction hose
24 Dirt water reservoir, detachable
25 Carrying handle of the wastewater con-
tainer
26 Seal on the lid
27 Fluff filter
 Check high power cable, extension ca-
bles and hoses for damage every time
before use.
 Attach the elbow to the hand nozzle and
hand-tighten the union nut on the el-
bow.
 Insert the suction hose into the suction
hose connection on the appliance.
Attach the coupling of the spray hose to
the spray hose connection of the appli-
ance and snap in place.
 Connect the suction hose to the elbow.
Connect the coupling of the spray hose
with the manifold and snap in place.
몇 Warning
Health risk, risk of damage. Observe all in-
dications on the detergent used.
 Mix fresh water and detergent in a clean
container (use the concentration rec-
ommended for the detergent).
Dissolve detergent in the water.
Note: Warm water (max. 50°C) will in-
crease the cleaning effect. Verify the tem-
perature resistance of the surface to be
cleaned.
Note: For considerate treatment of the en-
vironment use detergent economically.
 Fill detergent solution into the fresh wa-
ter reservoir. The fill level must not ex-
ceed the "MAX" mark.
Overview
Quick start instructions
Device elements
Start up
Attaching the Accessories
Prepare cleaning solution
Fill up fresh water reservoir
12 EN

Kärcher Puzzi 8/1 C Specifications

General

Type	Drum vacuum
Cleaning type	Wet
Dust capacity	- L
Product color	Black, Grey, Yellow
Dust container type	Bagless
Cord length	7.5 m
Carrying handle(s)	Yes
Maximum area covered	18 m²
Clean water tank capacity	8 L
Dirty water tank capacity	7 L
Airflow	61 l/s
Proper use	Professional
Noise level	- dB
Cleaning surfaces	Carpet, Hard floor
Vacuum air filtering	Water
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Maximum input power	1200 W
Annual energy consumption	- kWh

Weight and Dimensions

Depth	530 mm
Width	330 mm
Height	440 mm
Weight	9800 g
