Kärcher SC 3 Upright EasyFix User Manual

10 English
Note
Please ensure that steam stage 3
(tiles/stone) is set, otherwise the warm-
up time frame will be longer.
Installation
Installing the handle bar
1. Hold the basic device.
2. Fit the handle bar all the way to the
end stop into the basic device until it
audibly latches into place. The han-
dle bar must sit tightly in the device.
Installing the floor nozzle
1. Hold the device by the handle.
2. Connect the lower section of the ba-
sic unit to the floor nozzle until it au-
dibly latches into place.
Operation
Unwinding the power cord
몇 WARNING
Risk of electric shock
If the power cable is not completely un-
wound, the danger exists straining and
damaging the mains cable by overesti-
mating the range of the cable.
Always completely unwind the power
cable.
Note
The lower cable holder can be rotated
by 360° for removing the cable. The
upper cable holder cannot be rotated.
1. Turn the lower cable holder up-
wards.
2. Completely remove the power cable
from the cable holder.
3. Fasten the cable in the fastener of
the upper or lower cable holder to
prevent it from being run over during
cleaning work.
1.
2.
3.

Kärcher SC 3 Upright EasyFix Specifications

General

Type	Steam mop
Capacity	0.5 L
Control type	Buttons
Product color	Black, Grey, Yellow
International Protection (IP) code	IPX4
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Ready time	0.5 min
Steam pressure	- bar
Adjustable steam	Yes
Continuous steam performance	40 g/min
Cable length	5 m
Steam-ready light	-

Weight and Dimensions

Depth	314 mm
Width	207 mm
Height	1185 mm
Weight	3100 g
