Kärcher SC 3 Upright EasyFix User Manual

English 17
Abrasive floor cloth
The abrasive floor cloth is suitable for
cleaning insensitive surfaces such as
tiles or stone.
ATTENTION
Damage to floor coverings
The abrasive floor cloth can damage
sensitive floor coverings and surfaces.
Do not use the abrasive floor cloth for
cleaning wooden surfaces.
Do not use the abrasive cloth with the
carpet glider.
Removing the floor cleaning cloth
1. Place one foot on the bottom corner
of the floor cleaning cloth and lift the
floor nozzle up.
Note
Initially, the floor cleaning cloth's hook
and loop fastener strip is very strong
and cannot be removed from the floor
nozzle easily. After the floor cleaning
cloth has been used several times and
washed, it is easier to remove from the
floor nozzle and it has reached the op-
timum adhesion.
Removing the floor nozzle from the
basic device
ATTENTION
Material damage due to an unstable
device
Removing the floor nozzle makes the
device unstable and it can tip over and
damage the device and floor covering.
Do not remove the floor nozzle from
the basic device after installation.
Remove the floor nozzle only when
sending the device for servicing.
1. Press the OFF switch
2. Unplug the device from the outlet.
3. Empty the water reservoir.
4. Hold the device by the handle.
5. Actuate the unlocking button on the
floor nozzle.
1.
2.
OFF
1.
2.
3.
4.

Kärcher SC 3 Upright EasyFix Specifications

General

Type	Steam mop
Capacity	0.5 L
Control type	Buttons
Product color	Black, Grey, Yellow
International Protection (IP) code	IPX4
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Ready time	0.5 min
Steam pressure	- bar
Adjustable steam	Yes
Continuous steam performance	40 g/min
Cable length	5 m
Steam-ready light	-

Weight and Dimensions

Depth	314 mm
Width	207 mm
Height	1185 mm
Weight	3100 g
