Kärcher SC 3 Quick Reference

– 10
 Hold down the RESET button for 4 seconds after
inserting the cartridge.
Subject to technical modifications!
RESET button was not pushed after the
replacement of the cartridge
Technical specifications
Power connection
Voltage 220-240 V
1~50-60 Hz
Protection class IPX4
Protective class I
Performance data
Heating output 1900 W
Operating pressure max. 0,35 MPa
Heating time 30 Seconds
Steam volume
Continuous steaming
Steam push max.
40
100
g/min
g/min
Filling quantity
Water reservoir 1,0 l
Dimensions
Weight (without accessories) 3,2 kg
Length 360 mm
Width 236 mm
Height 252 mm
16 EN

Kärcher SC 3 Specifications

General

Type	Cylinder steam cleaner
Capacity	1 L
Cord length	4 m
Hose length	2 m
Product color	Black, Yellow
International Protection (IP) code	IPX4
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Steam pressure	3.5 bar
Continuous steam performance	40 g/min
On/off switch	Yes

Weight and Dimensions

Depth	360 mm
Width	236 mm
Height	253 mm
Weight	3.14 g
