– 6
Subject to technical modifications!
Technical specifications
SCP 6000 SCP 7000 SDP 7000
Voltage V 230-240 230-240 230-240
Frequency Hz 50 50 50
Output P
nom
W 250 280 320
Max. flow rate l/h 6000 7000 7000
Max. pressure MPa
(bar)
0,05
(0,5)
0,06
(0,6)
0,06
(0,6)
Max. flow height m 5 6 6
Max. immersion depth m 8 8 8
Max. grain size of the dirt particles
that can be transported
mm 5 5 20
Max. solid content in the water kg/m
3
2,0 2,0 10,0
Weight kg 4 4,2 4,3
Sound levels (EN 60704-1) dB(A) 49 49 49
The possible feed volume is even larger:
- the lower the suction and flow heights
- the larger the diameter of the hoses used
- the shorter the hoses used are
- the lower the pressure loss caused by the connected accessories
16 EN
