Subject to technical modifications!
Technical specifications
SCP 9000 SDP 9500
Voltage V 230 - 240 230 - 240
Current type Hz 50 50
Output P
nom
W 350 450
Max. flow rate l/h 9000 9500
Max. pressure MPa (bar) 0,07
(0,7)
0,06
(0,6)
Max. flow height m 7 6
Max. immersion depth m 9 9
Max. grain size of the dirt particles
that can be transported
mm 5 20
Weight kg 4,2 4,3
The possible feed volume is even larger:
- the lower the suction and flow heights
- the larger the diameter of the hoses used
- the shorter the hoses used are
- the lower the pressure loss caused by the connected accessories
20 EN
