Technical specifications
SCP 12000 SDP 14000
Voltage V 230 - 240 230 - 240
Current type Hz 50 50
Output P
nom
W 600 800
Protective class I I
Max. flow rate* l/h 12000 14000
Max. pressure MPa
(bar)
0,07
(0,7)
0,08
(0,8)
Max. flow height m 7 8
Max. immersion depth m 8 8
Max. grain size of the dirt particles
that can be transported
mm 5 25
Max. solid content in the water kg/m
3
2,0 10
Weight kg 6,5 6,8
Subject to technical modifications!
*The max. flow rate is derived from the measurement without the backflow valve installed.
The possible feed volume is even larger:
- the lower the suction and flow heights
- the larger the diameter of the hoses used
- the shorter the hoses used are
- the lower the pressure loss caused by the connected accessories
