Kärcher Winner 11 - Technical Specifications; Power and Water Connection Details; Performance and Dimensions

English 9
Subject to technical modifications!
Technical specifications
Power connection
Voltage 220-240
1~50/60
V
Hz
Power consumption 6 A
Mains fuse (slow-blow) 10 A
Protective class II
Protection class IP X5
Water connection
Max. feed temperature 40 °C
Min. feed volume 8 I/min
Feed pressure 0,2-1,2 MPa
Performance data
Working pressure 8 MPa
Max. permissible pressure 10 MPa
Water flow rate 5,5 I/min
Detergent flow rate 0,4 I/min
Recoil force of trigger gun 10 N
Hand-arm vibration
(ISO 5349)
0,8 m/s
2
Sound pressure level
L
pA
(EN60704-1)
78 dB(A)
Sound power level
L
WA
(2000/14/EG)
92 dB(A)
Dimensions
Length 229 mm
Width 314 mm
Height 572 mm
Weight 5,0 kg
