Kargo Master PRO-III - Page 3

2011 KargoMaster-'Pro 3 & 4' _4.1
E
(2 ea.)
5/16" x 2 1/4"
Button Head Bolt
F
(8 ea.)
5/16" x 3/4"
Button Head Bolt
H
A
G
J
K
(14 ea.)
1/2" SAE Flat Washer
(22 ea.) 3/8" SAE Flat Washer
U
(4 ea.)
3/8" Lock Washer
(14 ea.) 5/16" Flat Washer
(4 ea.)
L
(6 ea.)
M
(10 ea.)
N
(14 ea.)
(4 ea.)
1/2" x 3 1/2"
Hex Bolt
5/16" x 3/4"
Carriage Bolt
1/2" Jam Nut
3/8" Lock Nut 5/16" Lock Nut
D
(8 ea.)
3/8" x 1 3/4"
Button Head
C
(2 ea.)
3/8" x 2 1/4"
Button Head
T
(2 ea.)
3/8" x 16 x 2 1/2"
Button Head Bolt
B
(2 ea.)
1/2" x 2 1/4"
Button Head Bolt
S
(6 ea.)
1/2" x 13 x 2 1/2"
Button Head Bolt
P
(4 ea.)
5/16" x 3/8"
Allen Head Set Screw
Q
(2 ea.)
3/8” T Nut
R
(6 ea.)
Bed Rail
Clamps
(yellow zinc plated, grade 5)
(yellow zinc plated, grade 5)
(yellow zinc plated, grade 5)
