STEP 9
STEP 10
P
#1 = Lift rake onto truck and make
final adjustments and attach front
and rear legs with bolts A, washers
H, and nut L.
Center rack on truck bed.
Tighten up the bolts on the crossbar and clamp
plates as well as the set screws P.
#1 = Attach the front SUPPORT
UPRIGHT
where the 1” tube begins
to bend downward, then...
TIGHTEN DOWN EVERYTHING AND....
THAT’S IT!
You’re ready to LOAD & GO!
N
K
G
L
H
H
A
