Karma KM-8000 Series User Manual

10
While completing step 2, never put your fingers around
the sides or under the wheelchair as they can be trapped
between the seat and the frame. (See the right figure.)
4.1.2 Folding
4.1.2.1 Flip up the footplates. (See Figure 4.7)
4.1.2.2 Disassemble the footrest. (See Figure 4.8)
4.1.2.3 Separate the backrest upholstery from underneath the seat. (See Figure 4.9)
4.1.2.4 Pull up on the seat upholstery by holding it in the centre of its front and
back edge. (See Figure 4.10)
4.1.2.5 Press the two release levers on the backrest frame (push handle tubes) to
fold the backrest down for compact storage and easy transport. (See Figure
4.11)
4.1.2.6 Folding is now completed.
Figure 4.7
Figure 4.8
Figure 4.9
Figure 4.10
Figure 4.11
CAUTION:
● Be careful not to get your fingers caught when folding the wheelchair.
