19
5.13.1.1 Pull and hold the adjustment ring away from the adjustment plate. (See
Figure 5.13)
5.13.1.2 While holding the adjustment ring, adjust the steering column angle to
the desired position.
5.13.1.3 Let go of the ring when the steering column angle matches one of the
four designed positions in the adjustment plate.
5.13.1.4 Gently push/pull against the steering column to ensure that the steering
column is securely engaged into the locking mechanism. The adjustment
pin will automatically slide into the hole and make a "click" sound. (See
Figure 5.14)
5.13.1.5 Be sure the steering column is securely locked into position; otherwise you
may fall from the scooter and get injured.
Figure 5.13 Figure 5.14
5.13.2 Type 2: Rotating Steering Column Adjustment.
5.13.2.1 Pull the steering column adjustment lever until its locking mechanism
releases. (See Figure 5.15)
513.2.2 While holding the adjustment lever in and holding on to the handlebars
with both hands; raise or lower the steering column to the desired position.
There are approximately five positions to choose from.
5.13.2.3 When you release the adjustment lever; the steering column will lock in
place. You may have to move the steering column slightly up or down to
hear it "click" into the locked position. (See Figure 5.16)
