Karma STAR Series User Manual

15
with the hole. (Figure 4-23)
4.1.8.3 Fix the footrest with the sleeve and tube. (Figure 4-24)
4.1.8.4 Lock the footrest with screws and Hex. nut. (Figure 4-25)
Adjust footrest:
4.1.8.5 Loose screws by using 5mm Allen key which bundled in the tool box and
adjust the length to an appropriate position to fit user’s leg-length.
(Figure 4-26)
Figure 4.22
Figure 4.23
Figure 4.24
Figure 4.25
Figure 4.26
4.2 Transferring In and Out
4.2.1 Transferring In
4.2.1.1 Engage both hand brakes.
4.2.1.2 Turn the footplates up and swing them to the side.
4.2.1.3 The user lowers his or her body into the seat using the armrests for
support.
4.2.1.4 Turn the footplates back down, so that the user can place his feet on them.
4.2.1.5 Release both hand brakes.
CAUTION:
● Always ensure that the front casters are in line with the rear wheels and
pointing forwards and that the back of the wheelchair is secure either against
a wall or firmly held by an attendant.

Karma STAR Series Specifications

General

Type	Manual Wheelchair
Foldable	Yes
Frame Material	Aluminum
Weight Capacity	250 lbs
Seat Width	16, 18, 20 inches
Seat Depth	16 inches
Armrest Height	9 inches
Wheel Size	24 inches
Backrest Height	43 cm (17")
