Mini lift and tilt roof hatch
DOORS, WINDOWS, STORAGE SPACE
3-7
Opening and closing
To open the mini hatch, first press button A,
in order to free the bar. Pushing bar B allows
the hatch to be opened in three positions. In
the central position the bar can be fixed with
slider C.
To lock the hatch securely in the driving or
rest position, the bar must latch in behind
button A.
Operation of blind / insect grille
The mini hatch has a shade blind and an
insect grille. In order to darken, take the
closing bar of the blind and allow it to latch in
the opposite bar of the insect grille. Now
blind and insect grille can be brought into any
desired intermediate position.
To open, push the joined bars in the shade
direction. Separate the bars by pushing rocker
D with one hand and pushing the blind back
with the other hand. Do not allow the blind to
shoot back uncontrolled.
Safety instructions
Do not step on the acrylic glass
Close the hatch completely before starting
you journey
Close the hatch before leaving the vehicle
(risk of burglary or rain)
Do not open in strong winds or rain
Before opening, remove ice, snow leaves
or any other similar items
Do not use pressure washers, solvents or
cleaning materials containing alcohol.
B
A
D
In strong sunlight the shade blind may
only be closed 2/3 (plastic parts may be
damaged if heat builds up between the
blind and the glass).
Blinds may not be closed during travel!
Caution
