2HP-5HP VFX AERATOR MANUAL
8
ASSEMBLY INSTRUCTIONS (CONT.)
11. Slide the clips toward the center and over the bottom screen so that one of the vertical bars is between
the two anges on each clip as shown. Tighten all three serrated hex head screws to secure the screen
to the bottom of the oat, being sure not to pinch the power cord. 9/16’’ socket or combination wrench
required.
Tighten all
3 screws to
secure oat
screen
Vertical bar in be-
tween clip anges
Providing strain relief on the cord helps ensure that
its weight and any strain placed on it in the water will
not cause the oat to tilt or cause damage to the unit.
If your Kasco cord comes with a strain relief kit at-
tached, attach the available link to the oat-side knot
in the mooring rope, as pictured here.
Cord Strain Relief
