2HP-5HP VFX AERATOR MANUAL
7
ASSEMBLY INSTRUCTIONS (CONT.)
5. Wrap the at mesh into a cone shape by overlapping both vertical edges by approximately 1 inch and
aligning the top and bottom edges of mesh.
6. Use three cable ties evenly spaced along the vertical seam to secure the mesh at the top, middle, and
bottom.
7. Center the stainless steel bottom screen inside the mesh cone with approximately 2 inches of mesh
above the steel screen's large ring.
8. Use three cable ties evenly spaced around the large ring to attach the mesh to the steel screen.
9. Use two cable ties placed opposite each other on the small ring to further secure the mesh to the
screen.
5
7
8
6
9
Dedicated power
cord channel
J
10. Lift the unit and slide the bottom oat screen (I) with the mesh over the can and up to the bottom of the
oat, allowing the unit power cord to exit between them in the dedicated channel.
