Speed Limit
10 km/h
Speed Limit
25 km/h
Speed Limit
60 km/h
8.9 Poles in motor : Magnetic poles inside the motor, press UP/DOWN will change pole
number, range 0~10. Default value is 1.
Speed Poles
0
Speed Poles
1
Speed Poles
10
8.10 Start after poles : How many poles (speed sensor) need to be detected by controller
before starting motor. Default value is 3.
Start Poles
1
Start Poles
2
Start Poles
3
8.11 Assist levels : This parameter can customize assist levels, options are 3/5/9.
Assist
3
Assist
5
Assist
9
9． Error Code define
500C can show warning message, icon shows on the screen, and show error code at
the bottom of the screen, error code is from 01 E~07 E, and the definition see the table
below.
Error Code
Error description
Handle
01E
Communication Error
Check the cable connection
02E
Controller protection
Check three-phase power line.
03E
three-phase power error
Check three-phase power line connection
04E
Battery low
Charge the battery
05E
Brake error
Check the brake connection.
06E
Throttle error
Check turn to connect.
07E
Hall error
Check the hall connection
08-99E
Reserved
Please contact the manufacturer for error definitions
