W H E E L B L A N C E R
- 14 -
corresponding weight of lead block is attached behind the spokes by pulling the
ruler.
Rotate the tire slowly again until the second unbalance value appears on the
middle display screen. At this time, stick the lead block with the corresponding
weight in the way above, and the tire is balanced.
Note: At this point, press < FINE > to see that the balance precision is 1g. To
return to the normal unbalance value display, press < START > or < C >.
4．5 Tires Balance
I Press Start button to START. After
automatic braking, the display is as shown in the
figure below:
Is the inside error of the tire
Is the error value of tire outside
II Slowly turn the tire, when the inside lights are
all on, put a 40g lead block on the inside side of
the rim just above the vertical spindle, as shown
in the figure:
