physically check to make sure that the lift platforms raise up enough to allow BOTH Safety LockBars to FULLY
disengage from the Safety Lock Bars mounted onthe frame. Neither of the Safety Lock Bars should engage
theframe’s lock bar if the lift is to be lowered all the way to the ground.
If one (but not both) of the lock bars should engage before the lift reaches the ground, (platforms will become
unlevel) then damage to the lift frame may occur.
If the operator does NOT WANT TO LOWER THE VEHICLE ALL THE WAY TO THE GROUND, (perhaps only a
few inches from the current raised position), then the operator must make sure that both of the Safety Lock Bars
are fully disengaged during the lowering process.After pressing the “DOWN” button on the remote console, the
platforms begin to move down and the lock bars release (disengage). As the lift platforms
descend to the desired lower locking position (lock bars are disengaged), the operator should make sure that when
the desired position is reached that both lock bars fully engage the frame’s horizontal SafetyLock Bars at the same
time and at the same position so that the platforms remain LEVEL.
•
Position the vehicle at the centre of the platform. Check to make sure that
• Place the pads in the positions;
•
Set the power switch to 1 position;
• Press the lifting button to raise the vehicle;
• To rest the lift in standing position at the desired height by releasing the
7.3 To Lower The Lift
•
Be sure the safety area is free of people and objects;
• Press the lowering button, the lift will be raised a little bit to assure the
•
Keep pressing the lowering button to lower the lift completely.
7.4 To Move The Lift
When the lift needs to be moved, proceed as below:
• Place the lift at a proper height;
•
Attach the hook placed on the carriage to the hole placed universal
wheel hole on the front beam
• Pull the carriage to move the lift.
