Technical Speci fi cation
4.1 Size And Main Features
CAPACITY
3500kg /7,716 LBS.
Max. lifting height
1050mm/41” (With positioning
blocks)
Min. lift height
110mm/4.33”
Length of the platform
1430-2036mm/56.3-80.16”
Width of platform
500mm/19.69”
Free width between platforms
860mm/33.86
Overall length
2036mm/80.16”
Overall width
1860mm/43.23
Lifting time
35s
Lowering time
40s
Compressed air pressure
85-120 psi.
Noise level
80 dB(A)/1m
Working temperature
14 °F - 104 °F
The weight of these two packages
is 600kg
600kg/1323LBS.
2036mm/80.16
1430mm/56.3”
110-1050mm
/4.33-14”
1860mm/
43.23”
500mm/19.69”
860mm/33.86”
