28
Nos.
Part Nos.
Name
Quantity
1
YL-ZWXJ-01-01-00A
Left base welding
1
2
YL-ZWXJ-01-01-00B
Right base welding
1
3
8108
Limit switch
1
4
RH000510
Snap-head bolt M5X10
4
5
YL-ZWXJ-00-01
Top tile seat (without platform)
2
6
YL-ZWXJ-00-02
Top tile seat (with platform)
2
7
IH001045
inside hexagonal bolt M10X45
8
8
YL-ZWXJ-00-03
Bottom slide block(left)
2
9
YL-ZWXJ-00-04
Bottom slide block(right)
2
10
SDA-20*15 M5
Thin cylinder
2
11
YL-ZWXJ-06-00
Lock frame
2
12
YL-ZWXJ-00-05
Middle axle
4
13
YL-ZWXJ-00-06
Flower mat
4
14
W002000
Φ20 flat washer
4
15
YL-ZWXJ-00-07
Round nut M20
4
16
YL-ZWXJ-00-08
Fixed shaft for lock frame
2
17
RH000512
Snap-head bolt M5X12
8
18
SF-2530
Oilless bearing
4
19
YL-ZWXJ-00-09
Fixed shaft for power arm
2
20
YL-ZWXJ-03-00
Internal arm welding
1
21
ST000810
Jackscrew M8X10
16
22
Oil cylinder
2
23
YL-ZWXJ-02-00
Outside arm welding
1
24
SF-3025
Oilless bearing
4
25
SF-3050
Oilless bearing
4
26
YL-ZWXJ-00-10
Oil cylinder casing
4
27
YL-ZWXJ-00-11
Fixed shaft on cylinder
2
28
YL-ZWXJ-04-00
Power arm welding
2
29
YL-ZWXJ-00-12
The fixed axis for power arm walking
wheel
4
30
YL-ZWXJ-00-13
Power arm walking wheel
8
31
SF-2515
Oilless bearing
8
32
RE002500
Φ25 clamp spring
14
33
YL-ZWXJ-00-14
Upper cover slide shaft
4
34
YL-ZWXJ-00-15
Upper cover slider
4
35
YL-ZWXJ-00-16
Top cover fixed shaft
4
36
YL-ZWXJ-05-01-00A
top left cover plate welding
1
37
YL-ZWXJ-05-01-00B
top right cover plate welding
1
38
YL-ZWXJ-07-01-00A
Left mounting plate welding
2
39
YL-ZWXJ-07-01-00B
Right mounting plate welding
2
40
YL-ZWXJ-00-17
Mounting plate fixed shaft
4
41
RE001200
Φ12 clamp spring
30
42
YL-ZWXJ-00-18
Mounting plate walking wheel
8
43
YL-ZWXJ-00-19
Mounting plate walking axle
8
44
YL-ZWXJ-00-20-00
Mounting plate bracket welding
4
