CS11/CS8 MIDI Settings Manual
9
MIDI Exclusive Data Format
1st byte 2nd byte 3rd byte 4th byte 5th byte 6th byte 7th byte 8th byte 9th byte 10th byte
1 2 3 4 5 6 7 8 9 10
Byte ID Description
1 F0 Start code
2 40 Kawai ID number
3 00 - 0F MIDI channel
4 10, 30 Function code (30 when setting Multi-timbre On/O)
5 04 Indicates that the instrument is an electric piano
6 02 Indicates that the piano is a CA/ES model
7 data 1
See table below8 data 2
9 data 3
10 F7 End code
data 1 data 2 data 3 Function
00 00 - Multi-timbre O
01 00 - Multi-timbre On 1
02 00 - Multi-timbre On 2
0F 00 - 7F - Split Point
14 00 - 7F - Dual/Split balance
16 1F - 60 - Tune, 40: 440 Hz
17 00, 7F - 00: Program Change O, 7F: Program Chage On
18 00 - 07 -
00: Light, 01: Normal, 02: Heavy, 03: O, 04: Light +, 05: Heavy +,
06: User1, 07: User2
19 00 - 03 - Lower Octave Shift
20
00 - 3B 00 - 3B
Dual, data 2: Main sound, 3: Layer sound
00 - 4F * 00 - 4F *
21
00 - 3B 00 - 3B
Split, data 2: Upper sound, data 3: Lower sound
00 - 4F * 00 - 4F *
22
00 - 3B 00 - 3B
Four Hands, data 2: Right sound, data 3: Left sound
00 - 4F * 00 - 4F *
25 00 - 08 00 - 0B data 2: Temperament, data 3: Key
26 00, 7F 00 - 0F Multi-timbre channel mute, data 2: 00 (mute On), 7F (mute O), data 3: Channel
* CS11 onl y.
