Kawai CS8 - Stand Assy Parts

P26 Stand Assy Parts
CS8
No.
Qty
①
1
②
1
③
1
④
1
⑤
4
⑥
4
⑦
4
274918
END PANEL ASSY (R)
NEW
PEDAL BOARD ASSY
=CS7
951635
STAND BACK BOARD
797023
+Truss Self Tapping Screw Type A 4mm*16mm WHC
798120
+Truss Self Tapping Screw Type A 4mm*20mm BKC
Parts Code
Parts Name
Remarks
274917
END PANEL ASSY (L)
NEW
798368
+Truss Self Tapping Screw Type A 4mm*30mm BKC
