Kawai CS8 - Assembly Parts 6 of 7

P09 Assembly Parts 6 of 7
CS8
No. Qty
① 1
② 5
③ 6
④ 1
⑤ 1
⑥ 1
⑦ 1
⑧ 8
949825
Parts Code
Parts Name
Remarks
230699
WR88 TYPE KEYBOARD UNIT
797022
+Truss Self Tapping Screw Type A 4mm*12mm WHC or BKC
239080H
PWB E ASSY. KEP-592(4) [PANEL LOGIC]
=CS7
239033A
PWB E ASSY. KEP-583(1) [HP AMP]
=CA67
798326
+Binding Taptite Screw B Tite 4mm:8mm WHC or BKC
CONTROL PANEL SUPPORT
798909
Extra Low Head Flat Screw 5mm*20mm BKC
798917
+Pan Washer Double Sems Machine Screw M5*25mm BKC
