GB - 9
2.3.2 400 V class
Inverter size 10 12
Housing size B
Phases 3
Output rated power [kVA] 4 6.6
Max. rated motor power [kW] 2.2 4
Output rated current [A] 5.8 9.5
Max. short time current [A] 10.4 17
OC-tripping current [A] 12.5 21
Input rated current [A] 8 13
Max. permissible mains fuse (inert) [A] 16 20
Rated switching frequency [kHz] 4 4
Max. switching frequency [kHz] 8 8
Power loss at nominal operating [W] 64 95
Input rated voltage 1) [V] 400 (UL:400…480)
Input voltage range U
mains [V] 305…528 ±0
Mains forms TN, TT, IT
2)
, Delta
3)
Mains frequency [Hz] 50…60 ±2
Output voltage [V] 3 x 0…U
mains
Output frequency [Hz] 0…400
Min. motor line cross section [mm
2
] 1.5 2.5
Max. motor line length (shielded) [m] 30 at limit value class C2
With intergrated braking transistor
Typically braking resistor [Ω] 270 150
Maximal braking current [A] 10 10
Leakage current with internal lter (at nOP) [mA] 6
1)atmainsvoltage≥460Vmultiplythenominalcurrentwithfactor0.86.
2)insulatingresistanceatmainsformIT=2MΩ
3) on inquiry
