Page #26 background imageLoading...
Page #26 background image
A2xxOperation and handling
Operating instructions V1.01
26
© KEBA
Main menu
(1st level)
Display
(2nd level)
Description
Menu 4/5
Settings
Menu 8/16
MStartTrig
Mode for triggering the measurement in the Machine op-
erating mode (move down / motion). Default setting:
motion
move down: the measurement starts as soon as the
pressure beam moves faster than the speed set using the
MSpeed parameter.
motion: the measurement starts as soon as the set sen-
sitivity of the MSens parameter has been exceeded.
Menu 9/16
MStopTrig
Mode for stopping the measurement in the Machine op-
erating mode (move up / motion). Default setting:
move up
move down: the measurement stops as soon as the
pressure beam moves faster than the speed set using the
MSpeed parameter and a constant angle is measured.
motion: the measurement stops as soon as the set trip
limit of the MSens parameter has been exceeded and a
constant angle is measured.
Menu 10/16
MSlow
Setup parameters for longer measurement duration (up to
40s) in the Machine operating mode (off / on). Default
setting: off
MSlow
Off
Menu 11/16
MSpeed
Speed threshold for the motion detection of the pressure
beam in the Machine operating mode, in the move
down and move up mode from 0 to 200 mm/s, default
setting: 20
2)
MSpeed
20
Menu 12/16
MSens
Trip limit of the acceleration sensor from which a move-
ment of the pressure beam in the Machine operating
mode, in the motion mode, is detected from 0 to 200,
default setting: 50
3)
MSens
50
Menu 13/16
MAccuracy
Tolerance value from which a plateau in the angle value is
detected from 0 to 50 (1/value) °, default setting: 20
4)
MAccuracy
20
Menu 14/16
MSymRefl
In the machine operating mode, filtering reflections that
are not symmetrical to the vertical axis can be configured
(on / off).
On: Reflections that are not symmetrical to the vertical
axis are filtered. Only symmetrical reflections are evalu-
ated for the angle value measurement. (Default setting)
Off: All reflections are evaluated for the angle value mea-
surement.
