Outdoor Unit Sizes 9K-12K (208-230V) (continued)
Sound Blanket
NOTE: Remove the panel plate, electrical parts, and fan assembly (refer to Panel Plate, Electrical parts, Fan assembly)
before disassembling the sound blanket.
Recover refrigerant from the refrigerant circuit before removing the
compressor.
WARNING
noitartsullIerudecorP
1) Remove the sound blanket (side and
top).
Sound Blanket (side)
Sound Blanket (top)
To Next Page
