32808000903 Specifications subject to change without notice. 51
Outdoor Unit Sizes 9K-12K (208-230V) (continued)
Four-way valve
NOTE: Remove the panel plate, electrical parts, and fan assembly (refer to Panel plate, Electrical parts, and Fan
assembly) before disassembling the four-way valve.
noitartsullIerudecorP
1) Heat up the brazed parts then detach the
four-way valve and the pipe.
2) Remove the four-way valve assembly with
pliers.
To Next Page
