77
under cover removal
1. unscrew screw② and bolt①
2. removing under cover by loosing the left and right tapping screws④；
.
under cover installation
3．The sequence if installation is ther reverse of removal.
.
front cover removal
1．Unscrew tapping screw①, and remove front cover③ by removing front cover screw②
②
①
①
②
①
④
③
①
② ②
②
④
①
②
③
