Decide th length between the webs referring to the figure at
righ when rebuilding the crankshaft.
Standard width between webs:：
：：
：38±0.1mm(1.496±0.004in)
when mounting the crankshaft into crankcase, it is
necessaryto pull its left end into the crankcase with the
special tool.
CAUTION: Never fit the crankshaft into the the crankcase by driving it
with a plastic hammer. Always use the special tool, otherwise crankshaft
alignment accuracy will be affected.
