KEF R3 Meta User Manual

8 9
225mm (9") MIN.
W: 1.5 - 3 m (5 f t. - 10 f t.)
D: 1 - 1.2 x W
0.5m (20") MIN.
225mm (9") MIN.
0 - 15° 0 - 15°
0.5m (20") MIN.
Opt ional
KEF Subwoofer
Opt ional
KEF Subwoofer
0 - 15°
FL
A
5.2 / 7.2
FR
C
0 - 15°
SL
SR
RRRL
W: ≥A
D: 1 - 1.2 x W

KEF R3 Meta Specifications

General

Type	3-way bass reflex
Sensitivity	87dB (2.83V/1m)
Maximum Output	110dB
Frequency Range (-6dB)	38Hz - 50kHz
Amplifier Power	15-180W
Nominal Impedance	4 Ohms (min. 3.2 Ohms)
Finish Options	Black / White / Walnut
Frequency Response	58Hz - 28kHz (±3dB)
Drive Units	Uni-Q Driver Array: 25mm (1in.) vented aluminium dome tweeter with Metamaterial Absorption Technology (MAT), 125mm (5in.) aluminium midrange; 165mm (6.5in.) aluminium woofer
