Keithley 2260B-30-36 Quick Start Guide

2260B Series Quick Start Guide
22
4. Use the Current knob to set the F-
03 setting.
Set F-03 to 0 (CV High Speed
Priority) or 2 (CV Slew Rate
Priority).
Current
F-03
0 = CV High Speed Priority
2 = CV Slew Rate Priority
5. Press the Voltage knob to save the
configuration setting. ConF will be
displayed when successful.
Voltage
6. If CV Slew Rate Priority was chosen as the
operating mode, repeat steps 3~5 to set F-04
(Rising Voltage Slew Rate) and the F-05
(Falling Voltage Slew Rate) and save.
F-04 / F-05
0.1V/s~60V/s (2260B-30-XX)
0.1V/s~160V/s (2260B-80-XX)
0.1V/s~500.0V/s (2260B-250-XX)
1V/s~1600V/s (2260B-800-XX)
7. Press the Function key again to
exit the configuration settings.
The function key light will turn
off.
8. Use the Current knob to set the
current limit (crossover point).
Current
