2260B Series User Manual
50
Note
Notice the Set key becomes illuminated when
setting the current or voltage. If the Voltage or
Current knobs are unresponsive, press the Set key
first.
10. Press the Output key. The Output
key becomes illuminated.
% W
V
A
C C
% W
20 40 60 80 100
CC and the Power Bar
will become illuminated
(bottom left & center)
Note
Only the current level can be altered when the
output is on. The voltage level can only be changed
by pressing the Set key.
