2260B Series User Manual
90
USB/GPIB Settings
Front Panel USB
State
Displays the front panel USB-A port state. This
setting is not configurable.
F-20
0 = Absent, 1 = Mass Storage
Rear Panel USB
State
Displays the rear panel USB-B port state. This
setting is not configurable.
F-21
0 = Absent, 2 = USB-CDC,
3 = GPIB-USB adapter
Rear Panel USB
Mode
Sets the rear panel USB mode.
F-22
0 = Disable, 1 = GPIB-USB
adapter (for 2260B-GPIB-USB),
2 = USB CDC
GPIB Address
Sets the GPIB address.
F-23
0~30
