12-10 SCPI Tables
:SENSe[1]
:PCURrent
:SYNChronize
:TLEVel
:RANGe
<NRf>
Set trigger level range (100mA, 1A, or 5A) for the
5A
current range. The parameter <NRf> sent
with this command causes the trigger to be set
with the trigger level setting of MILL, ONE, or
AMP. Queries receive responses of 0.1, 1.0, or
5.0 accordingly. In other words, if a value of
2.0A is sent with the command, a value of 5A
will be returned as a response to a query.
5A
:RANGe? Query selected trigger level range for the 5A
curr
ent range.
:MILLiamp
<NRf>
Model 2306-PJ only — when on 500mA current
range.
The parameter <NRf> sent with this
command causes the trigger to be set with the
trigger level setting of HALFamp, HUNDred,
or TEN.
:MILLiamp? Model 2306-PJ only — Query the trigger level
se
tting on the 500mA current range. Receives
responses in amps of 0.5, 0.1, or 0.01,
accordingly.
:DELay <NRf> Specify trigger delay in seconds:
0.0–0.1 (pulse current measurements) or
0.0–5.0 (pulse current digitization).
0.0
:DELay? Query specified trigger delay (dependent on
SYNC:ST
AT).
:FAST <b> Enable or disable pulse current fast readings. OFF
:FAST? Query pulse current fast reading setting.
:SEARch <b> Enable or disable pulse current search. ON
:SEARch? Query pulse current search setting.
:DETect <b> Enable or disable pulse current detection mode. OFF
:DETect? Query pulse current detection mode setting.
Table 12-4 (cont.)
SENSe command summary (refer to Tables 2-3, 3-2, and 4-2) (cont.)
Command Description
Default
parameter
SCPI
