Keithley 2306 User Manual

SCPI Tables 12-11
:SENSe[1]
:PCURrent
:TimeOUT <NRf> Specify length of timeout: 5ms - 32s incrementing in
1ms.
1 (sec)
:TimeOUT? Query pulse current timeout setting.
:LINTegration Path to configure long integration measurements (refer to
Section 4):
:TEDGe <name> Set trigger edge to start long integration measurement
(RISIN
G, FALLING, NEITHER).
RISING
:TEDGe? Query trigger edge setting.
:TIME <NRf> Set integration time in seconds: X to 60 where X is 0.850
fo
r 60Hz line frequency or 0.840 for 50Hz line
frequency.
1.00
:TIME? Query integration time.
:AUTO Power supply sets integration time.
:TLEVel Path to set trigger level.
[:AMP] <NRf> Set trigger level for 5A range: 0 to 5 (amps). 0
[:AMP]? Query trigger level for 5A range.
:ONE <NRf> Set trigger level for 1A range: 0 to 1 (amps). 0
:ONE? Query trigger level for 1A range.
:MILLiamp
<NRf>
Set trigger level for 100mA range: 0 to 0.1 (amps). 0
:MILLiamp? Query trigger level for 100mA range.
:HALFamp
<NRf>
Model 2306-PJ only — Set trigger level (in amps) for
500mA range on 500mA curre
nt range: 0-500mA
0.0
:HALFamp? Model 2306-PJ only — Query the 500mA trigger
le
vel setting on the 500mA current range.
:HUNDred
<NRf>
Model 2306-PJ only — Set trigger level (in amps) for
100mA range on 500mA curre
nt range: 0-100mA
0.0
:HUNDred? Model 2306-PJ only — Query the 100mA trigger
le
vel setting on the 500mA current range.
:TEN <NRf> Model 2306-PJ only — Set trigger level (in amps) for
10mA range on
500mA current range: 0-10mA
0.0
Table 12-4 (cont.)
SENSe command summary (refer to Tables 2-3, 3-2, and 4-2) (cont.)
Command Description
Default
parameter
SCPI
