Keithley 2306 User Manual

12-12 SCPI Tables
:SENSe[1]
:PCURrent
:LINTegration
:TEN? Model 2306-PJ only — Query the 10mA trigger level
se
tting on the 500mA current range.
:RANGe <NRf> Select trigger level range (100mA, 1A, 5A) for the 5A
curre
nt range based on <NRf> which causes AMP,
ONE, or MILL setting to be used for trigger level.
5.0
:RANGe? Query trigger level range for the 5A current range.
:MILLiamp
<NRf>
Model 2306-PJ only — when on 500mA current
range.
The parameter <NRf> sent with this
command causes the trigger to be set with the
trigger level setting of HALFamp, HUNDred, or
TEN.
:MILLiamp? Model 2306-PJ only — Query the trigger level
se
tting on the 500mA current range. Receives
responses in amps of 0.5, 0.1, or 0.01,
accordingly.
:TimeOUT <NRf> Specify length of timeout: 1 to 63 (seconds). 16
:TimeOUT? Query timeout.
:SEARch <b> Enable or disable pulse search. ON
:SEARch? Query state of pulse search.
:FAST <b> Enable or disable long integration fast readings mode. OFF
:FAST? Query long integration fast readings mode.
:DETect <b> Enable or disable long integration detect pulse only
mode.
OFF
:DETect? Query detect mode.
:SENSe2 SENSe subsystem for channel #2 (charger channel).
:FUNCtion <name> Select measurement function (“VOLTage,” “CURRent,”
“D
VMeter”, “PCURrent,” or “LINTegration”).
VOLT
:FUNCtion? Query measurement function.
:NPLCycles <n> Specify integration rate (in line cycles) for voltage, current,
and D
VM measurements (0.01 to 10).
1 ✓
:NPLCycles? Query integration rate. ✓
:AVERage <NRf> Specify the average count for voltage, current, and DVM
measurements (1
to 10).
1
Table 12-4 (cont.)
SENSe command summary (refer to Tables 2-3, 3-2, and 4-2) (cont.)
Command Description
Default
parameter
SCPI
