SCPI Tables 12-15

:SENSe2

:LINTegration

:TIME?

:AUTO Power supply sets integrations time.

:TLEVel <NRf> Set trigger level value 0–5A. 0

:TLEVel? Query trigger level setting.

:TimeOUT <NRf> Specify length of timeout: 1 to 63 (seconds). 16

:TimeOUT? Query timeout.

:SEARch <b> Enable or disable pulse search. ON

:SEARch? Query state of pulse search.

:FAST <b> Enable or disable long integration fast readings mode. OFF

:FAST? Query long integration fast readings mode.

:DETect <b> Enable or disable long integration detect pulse only

mode.

OFF

:DETect? Query detect mode.

Table 12-4 (cont.)

SENSe command summary (refer to Tables 2-3, 3-2, and 4-2) (cont.)

Command Description

Default

parameter

SCPI
