Performance Verification 13-17
1. Select the DMM DC volts function, and enable auto-ranging.
2. Select Channel #1 by pressing the
â–²
and
â–²
keys to toggle between Channel #1 and
Channel #2, and enable the Model 2306 DVM input.
3. Turn on the Model 2306 source output.
4. Verify digital voltmeter input accuracy for each of the voltages listed in Ta
ble 13-8. For
each test point:
• Set the voltage to the indicated value as measured by the digital multimeter.
• Set current compliance to 0.25A.
• Allow the reading to settle.
• Verify that the Model 2306 voltage reading is within the limits given in the table.
1. Repeat steps 1 through 5 for Channel #2 (use the
â–²
and
â–²
keys to toggle between
Channel #1 and Channel #2).
Table 13-8
Digital voltmeter input accuracy limits
Model 2306 output
Voltage setting
1
Digital voltmeter input reading limits
(2 Years, 18°C-28°C)
5.00V 4.995 to 5.005V
10.00V 9.992 to 10.008V
14.00V 13.990 to 14.010V
1
As measured by digital multimeter.
