Keithley 2306 User Manual

Replaceable Parts 16-7
Table 16-2
Model 2306 analog board parts list
Circuit designation Description Keithley part no.
C400-403,405,406,411,413,418,420,421-424 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C404,C407,C604,C607 CAP, 2200P, 10%, 100V, CERAMIC C-430-2200P
C408,C549,C608,C749 CAP, 1000pF, 20%, 50V, CERAMIC C-418-1000P
C409,C609,C430,C783 CAP, 100PF, 5%, 100V, CERAMIC C-465-100P
C410,415,543,544,610,615,446,531,586 CAP, 0.01UF, 10%, 50V, CERAMIC C-491-.01
C412,414,416,447,449,566,612,614,616,477 CAP, 47P, 5%, 100V, CERAMIC C-465-47P
C417 CAP, 150PF, 5%, 100V, CERAMIC C-465-150P
C419,C523,C539,C619,C723,C739 CAP, 22UF, 20%, 25V, TANTALUM C-440-22
C427,C627 CAP, 10U, 20%, 35V, ALUMINUM C-562-10
C431,C432,C631,C632 CAP, 1500P, 20%, 700V C-560-1500P
C434,C435,C634,C635 CAP, 1000P, 10%, 100V, CERAMIC C-451-1000P
C436,C464,C636 CAP, 2.2U, 10%, 50V, TANTALUM C-563-2.2
C438,439,440,441,557,559,638-641,759,782 CAP, 22U, 20%, 25V, TANTALUM C-535-22
C442,448,487,529,537,567,583,588,600-603 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C450,C451,C650,C651 CAP, 0.47, 10%, 16V, CERAMIC C-565-.47
C452,C652 CAP, 0.15UF, 20%, 50V, CERAMIC C-418-.15
C453 CAP, 0.047U, 10%, 50V, CERAMIC C-491-.047
C455,C458 CAP, 33PF, 5%, 100V, CERAMIC C-465-33P
C457,459,462,465,468,469,471,473,474,476 CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
C460,C952 CAP, 22PF, 10%, 100V, CERAMIC C-451-22P
C461,C683,C699 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C466,C647,C649,C660 CAP, 47P, 5%, 100V, CERAMIC C-465-47P
C475,482,710,637,679,697,698,547,558 CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
C478,C494 CAP, 0.015UF, 10%, 50V, CERAMIC C-491-.015
C480,C532 CAP, 1UF, 20%, 35V, TANTALUM C-494-1
C481,C485,C536,C736 CAP, 2.2UF, 20%, 35V, TANTALUM C-476-2.2
C484,488,492,493,540,569,570,581,582,584 CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
C486,489,490,499,500,501,502,521,524,527 CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
C491 CAP, 150PF, 5%, 100V, CERAMIC C-465-150P
C495,C591 CAP, 220PF, 10%, 100V, CERAMIC C-451-220P
C503,C574,C575 CAP, 3300P, 10%, 500V, CERAMIC C-497-3300P
C504,C479,C590 CAP, 220PF, 10%, 100V, CERAMIC C-451-220P
C507,508,510,512,644,645,740,593,643,682 CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
C513,C535,C628,C629,C713,C735 CAP, 0.01, 5%, 50V, NPO C-514-.01
C514,C515,C517,C52
8,C714,C715,C717 CAP, 2.2U, 10%, 50V, TANTALUM C-563-2.2
C519,C719 CAP, 220UF, ±20%, 50V, ALUM ELEC C-507-220
