16-8 Replaceable Parts
C525,C560,C563,C737,C760,C763 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C526,C726 CAP, 10U, 20%, 35V, TANTALUM C-551-10
C530,533,545,546,555,556,755,756,766,767 CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
C538,C654,C656,C738,C595,C661 CAP, 10UF, 20%, 25V, TANTALUM C-440-10
C541,741 CAP, 1000pF, 20%, 50V, CERAMIC C-418-1000P
C542,C520,C534,C48
3,C552,C752,C633 CAP, 0.01UF, 10%, 50V, CERAMIC C-491-.01
C550,C750 CAP, 2200P, 10%, 25V, CERAMIC C-495-2200P
C561,C562,C564,C565,C761,C762,C76
4,
C765
CAP, 680U, 20%, 50V, ALUM ELEC C-578-680
C568,C630,C548,C579,C617 CAP, 100PF, 5%, 100V, CERAMIC C-465-100P
C572,C463,C437,C706,C708,C712,C74
7,
C758
CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
C573,C578,C701 CAP, 2200P, ±10%, 500V, CERAMIC C-497-2200P
C576,C577,C702,C720,C730,C734,C47
0,
C472
CAP, 3300P, 10%, 500V, CERAMIC C-497-3300P
C585,587,677,696,707,467,496,497,498,506 CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
C589 CAP, 2200P, 1%, 50V, CERAMIC C-532-2200P
C596,C662 CAP, 0.01uF, 20%, 50V, CERAMIC C-418-.01
C605,606,611,613,618,620-624,642,676,711 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C646,C658,C742,C743,C744,428,429,784,
785
CAP, 0.01UF, 10%, 50V, CERAMIC C-491-.01
C653 CAP, 0.047U, 10%, 50V, CERAMIC C-491-.047
C659,C675 CAP, 330P, 10%, 100V, CERAMIC C-451-330P
C674 CAP, 2200P, ±10%, 500V, CERAMIC C-497-2200P
C678,687,594,705,625,626,571,516,518,522 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C681 CAP, 33PF, 10%, 50V, MONO CERAMIC C-452-33P
C700,C786,C787,C688 CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
C703,C580 CAP, 390P, 10%, 100V, CERAMIC C-451-390P
C716,718,725,505,511,648,655,657,722 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C768,769,770,771,772,773,774,775,778,779 CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
C780,781,425,426,433,443,444,445,454,456 CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
CR400,600 DIODE, DUAL HSM-2822T31 RF-95
CR401,CR601 DIODE, BRIDGE PE05 RF-48
CR402,CR602 DIODE, SILICON, 53A4 RF-47
CR408,412,603,607,608,612,407 DIODE, SWITCHING, MMSD914T19 RF-112
CR409,CR609 DIODE, BARRIER, MBR745 RF-65
CR413,613 SCHOTTKY DIODE RF-125
Table 16-2
Model 2306 analog board parts list (cont.)
Circuit designation Description Keithley part no.
