Table 16-4

Model 2306 mechanical parts list

Description Keithley part no.

BEZEL, REAR 428-303D

CHASSIS 2306-301

COVER 2306-307A

FAN FN-34-3

FOOT 428-319A

FOOT, EXTRUDED FE-22A

FOOT, RUBBER FE-6

FUSE, EXP. 2A/5X20MM S-B FU-81

HANDLE 428-329F

LINE CORD CO-7

LINE FILTER LF-11

MEMBRANE SWITCH 2306-313A

MOUNTING EAR, LEFT 428-338B

MOUNTING EAR, RIGHT 428-328E

POWER ROD 704-313A

PRINTED FRONT PANEL V-2306-306A

REAR PANEL 2306-303

Replaceable Parts 16-15
