Keithley 2306 User Manual

16-16 Replaceable Parts
Table 16-5
Model 2306-VS digital board parts list
Circuit designation Description Keithley part no.
C101,C141,C201 CAP,10UF,20%,25V,TANTALUM C-440-10
C103,C104,C109,C110,C116-
C118
,C203,C204
CAP,2200P,10%,100V CERAMIC C-568-2200P
C105,C106,C107,C130,C205,C206,C20
7,
C230
CAP,100U,20%,20V ALUM ELEC C-583-100
C108,C114,C115,C127,C129,C135,C13
6,
C137
CAP,.1UF,20%,50V CERAMIC C-418-.1
C112,C113,C212,C213 CAP,10U,20%,35V TANTALUM C-551-10
C119,C152,C219,C252 CAP,.01UF,10%,50V CERAMIC C-491-.01
C120,C123,C131,C142,C156,C193,C19
6,
C220
CAP,.1UF,20%,50V CERAMIC C-418-.1
C121,C122,C221,C222 CAP,470U,20%,50V,ALUM ELEC C-570-470
C124,C126,C128,C153,C192,C194,C22
4,
C226
CAP,22UF,20%,25V,TANTALUM C-440-22
C125,C150,C225 CAP,22U,20%,25V TANTALUM C-535-22
C132,C133,C184,C186,C189,C197,C19
8,
C199
CAP,.1UF,20%,50V CERAMIC C-418-.1
C138,C139 CAP,,47U,20%,25V C-520-.47
C143,C311 CAP,.022UF,10%,50V CERAMIC C-491-.022
C145,C270,C271,C309 CAP,270PF,5%,100V,CERAMIC C-465-270P
C146,C308 CAP,1000PF,10%,50V,MONO CERAMIC C-452-1000P
C147,C310 CAP,100PF,5%,100V CERAMIC C-465-100P
C148,C280,C281,C282,C320,C321 CAP,.01UF,20%,50V,CERAMIC C-418-.01
C149 CAP,,47U,20%,25V C-520-.47
C151,C158,C168,C169,C173,C175,C17
6,
C177
CAP,.1UF,20%,50V CERAMIC C-418-.1
C154 CAP,220UF,+/-20%,50V ALUM ELEC C-507-220
C155 CAP,.01UF,20%,50V,CERAMIC C-418-.01
C157 CAP,100UF,20%,16V TANTALUM C-504-100
C162,C262 CAP,47P,5%,100V,CERAMIC C-465-47P
C170,C174 CAP,.01UF,10%,50V CERAMIC C-491-.01
C171,C172 CAP,15P,1%,100V CERAMIC C-512-15P
C178,C179,C180,C181,C182,C188,C19
5,
C208
CAP,.1UF,20%,50V CERAMIC C-418-.1
C190,C191,C234,C25
9-C261,C263-C267,
C306
CAP,.1UF,20%,50V CERAMIC C-418-.1
C202,C300,C312 CAP,.1UF,20%,50V CERAMIC C-418-.1
C209,C210,C216-C218 CAP,2200P,10%,100V CERAMIC C-568-2200P
