Keithley 2306 User Manual

Replaceable Parts 16-17
C211,C102,C134,C144,C159-C161,
C163-C167
CAP,.1UF,20%,50V CERAMIC C-418-.1
C214,C215,C227,C229,C258,C268,C18
3,
C111
CAP,.1UF,20%,50V CERAMIC C-418-.1
C223,C231,C307,C233,C236,C333,C33
6 CAP,.1UF,20%,50V CERAMIC C-418-.1
C228,C140 CAP,22UF,20%,25V,TANTALUM C-440-22
C232,C235,C332,C335 CAP,2.2U,10%,50V TANTALUM C-563-2.2
C303,C304,C305,C100,C200 CAP,47P,5%,100V,CERAMIC C-465-47P
CR100,CR200 DIODE,DUAL HSM-2822T31 RF-95
CR101,CR201 DIODE,POWER 200V,U1620R RF-135
CR102,CR202 ULTRA FAST BRIDGE RECTIFIER,
EDF1B
M
RF-123
CR104,CR106,CR204,CR206 DIODE,MBRS140T3 RF-110
CR107,CR207 DIODE,POWER 200V,U1620 RF-134
CR108 DIODE,MBR5130LT3 RF-115
CR109,CR110,CR209,CR210 DIODE,SWITCHING,MMSD914T19 RF-112
CR112,CR115-CR118,CR212 DIODE,DUAL SWITCHING,BAV99L RF-82
F100,F200 FUSE,5X20MM,6.3A FU-108-6.3
FH100,FH101,FH200,FH201 FUSE HOLDER,LITTLEFUSE,111501 FH-33
J1002 CONN,MOLEX,3-PIN CS-772-3
J1003 CONN,RIGHT ANGLE,24 PIN CS-501
J1006 LATCHING HEADER,FRICTON,SGL
R
OW
CS-724-3
J1007,J1010 CONN MALE 5-PIN CS-1060-5
J1008 CONN,HEADER STRAIGHT SOLDER PIN CS-368-10
J1009 CONN,HEADER STRAIGHT SOLDER PIN CS-368-34
L100,L101,L104,L116,L200,L201 LINE FILTER CH-85-10
L102 CHOKE CH-56-1
L103 POWER INDUCTOR CH-97-1
L105 CHOKE 1.2A CH-94-1
L106,L107,L109,L110,L111,L112 FERRITE CHIP 600 OHM BLM32A07 CH-62
L120,L121,L122 FERRITE CHIP 600 OHM BLM32A07 CH-62
L125,L126 CHOKE CH-131
PS100 POWER SUPPLY PS-72A
Q100,Q101,Q200,Q201 TRANS,POWER MOSFET,IRFZ46NS TG-371
R101,R105,R201,R205 RES,200,5%,250MW,METAL FILM R-376-200
R102,R111,R211,R212 RES,18.7,1%,1/4W METAL FILM R-391-18.7
Table 16-5
Model 2306-VS digital board parts list (cont.)
Circuit designation Description Keithley part no.
