Keithley 2306 User Manual

Replaceable Parts 16-23
C475,C482,C637,C679,C697,C698,C547,
C558
CAP,.01U,10%,25V CERAMIC C-495-.01
C478,C494 CAP,.015UF,10%,50V CERAMIC C-491-.015
C480,C668 CAP,1UF,20%,35V,TANTALUM C-494-1
C481,C485,C536,C736 CAP,2.2UF,20%,35V,TANTALUM C-476-2.2
C491,C417 CAP,150PF,5%,100V,CERAMIC C-465-150P
C493,C540,C569,C570,C581,C582,C58
4,
C585
CAP,.01U,10%,25V CERAMIC C-495-.01
C495,C591 CAP,220PF,10%,100V,CERAMIC C-451-220P
C501,C524,C767,C768,C769,C770,C77
8 CAP,.1UF,20%,50V CERAMIC C-418-.1
C503,C574,C575 CAP,3300P,10%,500V,CERAMIC
C-497-3300P
C504,C479,C590,C791,C793 CAP,220PF,10%,100V,CERAMIC C-451-220P
C506,C507,C508,C554,C512,C644,C64
5,
C740
CAP,.01U,10%,25V CERAMIC C-495-.01
C509,C709 CAP,.1UF,20%,50V CERAMIC C-418-.1
C510,C710,C789,C790 CAP,3300P,10%,500V,CERAMIC
C-497-3300P
C513,C535,C628,C629,C713,C735 CAP,.01,5%,50V,NPO (1812) C-514-.01
C514,C515,C517,C528,C714,C715,C71
7 CAP,2.2U,10%,50V TANTALUM C-563-2.2
C519,C719 CAP,220UF,+/-20%,50V ALUM ELEC C-507-220
C522,C525,C560,C563,C737,C760,C76
3 CAP,.1UF,20%,50V CERAMIC C-418-.1
C524,C527,C530,C533,C545,C546,C55
5,
C556
CAP,.1UF,10%,25V,CERAMIC C-495-.1
C526,C726 CAP,10U,20%,35V TANTALUM C-551-10
C532,C669 CAP,10U,20%,16V TANTALUM C-546-10
C538,C654,C656,C738,C595,C661 CAP,10UF,20%,25V,TANTALUM C-440-10
C541,C741 CAP,1000PF,20%,50V,MONO CERAMIC C-418-1000P
C542,C520,C534,C483,C552,C752,C63
3,
C807
CAP,.01UF,10%,50V CERAMIC C-491-.01
C548,C617 CAP,.01U,10%,25V CERAMIC C-495-.01
C550,C750 CAP,2200P,10%,25V,CERAMIC C-495-2200P
C554,C512,C644,C645,C740,C593,C64
3,
C682
CAP,.1UF,10%,25V,CERAMIC C-495-.1
C555,C530,C533,C502,C521,C527,C48
6,
C489
CAP,.1UF,20%,50V CERAMIC C-418-.1
C556,C755,C756,C425,C426,C433,C44
3,
C444
CAP,.01U,10%,25V CERAMIC C-495-.01
C558,C709,C572,C463,C437,C706,C70
8,
C712
CAP,.1UF,10%,25V,CERAMIC C-495-.1
Table 16-7
Model 2306-VS analog board parts list (cont.)
Circuit designation Description Keithley part no.
