16-24 Replaceable Parts
C561,C562,C564,C565,C761,C762,C764,
C765
CAP,680U,20%,50V ALUM ELEC C-578-680
C568,C579 CAP,100PF,5%,100V CERAMIC C-465-100P
C570,C581,C582,C584,C585,C587,C67
7,
C696
CAP,.1UF,10%,25V,CERAMIC C-495-.1
C572,C463,C437,C706,C708,C712,C74
7,
C758
CAP,.01U,10%,25V CERAMIC C-495-.01
C573,C578 CAP,2200P,+/-,10%,500V CERAMIC C-497-2200P
C576,C577,C702,C720,C730,C734,C47
0,
C472
CAP,3300P,10%,500V,CERAMIC C-497-3300P
C583,C588,C600-C603,C605,C606,C6
11,
C613
CAP,.1UF,20%,50V CERAMIC C-418-.1
C586,C670,C646,C658,C742,C743,C74
4,
C428
CAP,.01UF,10%,50V CERAMIC C-491-.01
C587,C677,C696,C707,C467,C496,C49
7,
C498
CAP,.01U,10%,25V CERAMIC C-495-.01
C593,C643,C682,C700,C786,C787,C68
8,
C753
CAP,.01U,10%,25V CERAMIC C-495-.01
C596,C662 CAP,.01UF,20%,50V,CERAMIC C-418-.01
C616,C477,C466,C647,C649,C660,C79
5 CAP,47P,5%,100V,CERAMIC C-465-47P
C618,C620-C624,C642,C676,C711,
C716
,C718
CAP,.1UF,20%,50V CERAMIC C-418-.1
C659,C675 CAP,330P,10%,100V CERAMIC C-451-330P
C674,C701,C589 CAP,2200P,1%,50V,CERAMIC C-532-2200P
C687,C594,C705,C625,C626,C571,C51
6,
C518
CAP,.1UF,20%,50V CERAMIC C-418-.1
C694,C551,C553,C806 CAP,.01UF,10%,50V CERAMIC C-491-.01
C700,C786,C787,C688,C671,C672,C67
3 CAP,.1UF,10%,25V,CERAMIC C-495-.1
C703,C580 CAP,390P,10%,100V,CERAMIC C-451-390P
C707,C467,C496,C497,C498,C506,C50
7,
C508
CAP,.1UF,10%,25V,CERAMIC C-495-.1
C725,C505,C511,C648,C655,C657,C72
2,
C678
CAP,.1UF,20%,50V CERAMIC C-418-.1
C747,C758,C548,C617 CAP,.1UF,10%,25V,CERAMIC C-495-.1
C753,C797,C801,C799,C805 CAP,.1UF,10%,25V,CERAMIC C-495-.1
C755,C756,C767.C768,C769,C770 CAP,.1UF,10%,25V,CERAMIC C-495-.1
C759,C782 CAP,22U,20%,25V TANTALUM C-535-22
C766,C771-C775,C490,C499,C500 CAP,.1UF,20%,50V CERAMIC C-418-.1
Table 16-7
Model 2306-VS analog board parts list (cont.)
Circuit designation Description Keithley part no.
