Replaceable Parts 16-25
C778,C779,C780,C781 CAP,.1UF,10%,25V,CERAMIC C-495-.1
C779,C780,C781,C671,C672,C673,C54
5,
C546
CAP,.1UF,20%,50V CERAMIC C-418-.1
C797,C801,C799,C805 CAP,.01U,10%,25V CERAMIC C-495-.01
C800 CAP,.022UF,10%,50V CERAMIC C-491-.022
C802,C804,C798 CAP,.022UF,10%,50V CERAMIC C-491-.022
CR400,600 DIODE,DUAL HSM-2822T31 RF-95
CR401,CR601 DIODE,BRIDGE PE05 RF-48
CR402,CR602 DIODE,SILICON,53A4 RF-47
CR403,CR410,CR411,CR413,CR414
,CR415 SCHOTTKY POWER RECTIFIER RF-126
CR407,CR405,CR406,CR416,CR417
,CR418 DIODE,SWITCHING,MMSD914T19 RF-112
CR408,CR412,CR603,CR607,CR608
,CR612 DIODE,SWITCHING,MMSD914T19 RF-112
CR409,CR609 DIODE,BARRIER,MBR745 RF-65
CR419,CR420,CR616,CR617,CR618 DIODE,SWITCHING,MMSD914T19 RF-112
CR421,CR422 SCHOTTKY POWER RECTIFIER RF-126
CR605,CR610,CR611,CR613,CR614
,CR615 SCHOTTKY POWER RECTIFIER RF-126
HS400,HS600 HEAT SINK HS-55
J1007,J1010 CONN MALE 5-PIN CS-1060-5
J1009 CONN,HEADER STRAIGHT SOLDER PIN CS-368-34
J1014,J1015 CONNECTOR,MODULES CS-834
L400,L401,L402,L405-L408,L600-L602
FERRITE CHIP 600 OHM BLM32A07 CH-62
L403,L404,L603,L604 FERRITE CHIP 600 OHM BLM32A07 CH-62
L409,L609,L413,L613,L414,L614 CHOKE,100U,SM INDUCTOR CH-66-100
L411,L611 CHOKE,19U,CHOKE,4.5A CH-98-1
L412,L612 CHOKE,22UH CH-66-22
L605-L608 FERRITE CHIP 600 OHM BLM32A07 CH-62
Q400,Q401,Q402,Q403,Q600,Q601,Q602,
Q603
TRANS,N-MOSFET,VN0605T TG-243
Q404,Q604,Q631,Q440,Q441 TRANS,NPN,MMBT3904 TG-238
Q405,Q605 TRANS,PNP,MMBT3906L TG-244
Q406,Q606 TRANS,POWER MOSFET,IRFZ46NS TG-371
Q407,Q408,Q607,Q608 HEXFET POWER MOSFET,IRFZ44N TG-354
Q409-Q416,Q431-Q438,Q610-Q616,Q609,
Q417
TRANS,N CHANNEL JFET,SNJ132199 TG-294
Q418,Q419,Q422,Q618,Q619,Q622 TRANS,N CHANNEL FET,2N4392 TG-128-1
Q421,Q621 CURRENT REGULATOR TG-366
Q423,Q623 PNP SILICON TRANSISTOR TG-310
Table 16-7
Model 2306-VS analog board parts list (cont.)
Circuit designation Description Keithley part no.
