Keithley 2306 User Manual

16-26 Replaceable Parts
Q424,Q429,Q620,Q624 N CHANNEL POWER MOSFET TG-349
Q425,Q430,Q625,Q629 P CHANNEL POWER MOSFET TG-348
Q426,Q626 NPN SILICON TRANSISTOR TG-309
Q427,Q428,Q627,Q628 TRANS,HEXFET POWER MOSFET,
IRFZ48NS
TG-376
Q630,Q632,Q633 TRANS,N CHANNEL JFET,SNJ132199 TG-294
R400,R600 RES NET TF-245
R401,R601 RES,6.04K,1%,125MW,THIN FILM R-423-6.04K
R402,R404,R602,R604 RES,2.21K,1%,100MW,THICK FILM R-418-2.21K
R403,R603 RES,1.28M,.1%,1/8W METAL FILM R-176-1.28M
R405,R414,R587,R588,R751,R752,R44
3,
R532
RES,10K,1%,100MW,THICK FILM R-418-10K
R406,R421,R606,R621,R796 RES,100,1%,100MW,THICK FILM R-418-100
R407,R463,R466,R468,R661,R662,R68
5,
R686
RES,1K,1%,100MW,THICK FILM R-418-1K
R408,R608 RES,5.11K,1%,100MW,THICK FILM R-418-5.11K
R409,R609,R454,R456,R761,R762 RES,470,5%,125MW METAL FILM R-375-470
R410,R412,R569,R610,R612,R660,R72
3 RES,2K,1%,100MW,THICK FILM R-418-2K
R411,R611,R504,R508 RES,10,10%,100MW,THICK FILM R-418-10
R413,R531,R613,R731 RES,6.04K,1%,100MW THICK FILM R-418-6.04K
R415,R615,R708,R735,R790 RES,49.9K,1%,100MW THICK FILM R-418-49.9K
R416,R616,R721,R724 RES,475,1%,100MW,THICK FILM R-418-475
R418,R618,R520,R521 RES,34K,1%,100MW,THICK FILM R-418-34K
R419,R619 RES,82.5,1&%,100MW,THICK FILM R-418-82.5
R420,R620 RES,4.75K,1%,100MW,THICK FILM R-418-4.75K
R422,R447,R622,R674,R496,R647 RES,100K,1%,100MW,THICK FILM R-418-100K
R423,R623 RES,3.01K,1%,1/4W METAL FILM R-391-3.01K
R424,R425,R570,R624,R625,R650 RES,10K,5%,250MW,METAL FILM R-376-10K
R426,R427,R449,R626,R627 RES NET,1K,9K,.1%,.25W TF-273-1
R429,R629 RES,.1,1%,3W R-475-.1
R430,R444,R460,R461,R467,R469,R47
0,
R455
RES,1K,1%,100MW,THICK FILM R-418-1K
R431,R631 RES,100,.1%,1/2W METAL FILM R-169-100
R432,R550,R450 RES,10K,5%,250MW,METAL FILM R-376-10K
R435,R438,R635,R638 RES,4.7K,5%,250MW,METAL FILM R-376-4.7K
R436,R636 RES,470K,5%,250MW,METAL FILM R-376-470K
R437,R597,R637,R671 RES,1M,.1%,.125MW THIN FILM R-456-1M
Table 16-7
Model 2306-VS analog board parts list (cont.)
Circuit designation Description Keithley part no.
