Keithley 2306 User Manual

Replaceable Parts 16-27
R439,R639 RES NET,5K,10K,.1%,25W TF-273-4
R440,R441,R640,R641 RES NET,20K,.1%,.25W TF-273-2
R442,R642,R764,R766,R784,R785,R47
9,
R704
RES,4.99K,1%,100MW,THICK FILM R-418-4.99K
R445,R645 RES,15K,1%,100MW,THICK FILM R-418-15K
R446,646 RES,909,1%,1W,THICK FILM R-418-909
R448,R648 RES,249K,1%,100MW,THICK FILM R-418-249K
R452,R453,R458,R451,R527 RES,2.55K,1%,1W THICK FILM R-418-2.55K
R457,R515 RES,2.74K,1%,.1W THICK FILM R-418-2.74K
R464,R472,R632,R750 RES,1K,5%,250MW METAL FILM R-376-1K
R465,R473,R522,R523,R786 RES,1M,1%,100MW,THICK FILM R-418-1M
R471,R512,R502,R596,R659,R664,R48
1,
R581
RES,10K,1%,100MW,THICK FILM R-418-10K
R474,R477,R677,R696,R495 RES,100K,1%,100MW,THICK FILM R-418-100K
R475,R478,R534,R580,R675,R678,R69
0,
R734
RES,4.99K,1%,100MW,THICK FILM R-418-4.99K
R476,R676,R595,R667,R582,R670,R77
9 RES,1M,1%,100MW,THICK FILM R-418-1M
R483,R683,R688,R689,R692,R693,R69
4,
R699
RES,10K,.1%,.125W THIN FILM R-456-10K
R484,R516,R518,R680,R681,R599,R79
4 RES,20K,1%,100MW,THICK FILM R-418-20K
R485,R486,R497,C498,C644,C549,R75
9,
R490
RES,1K,1%,100MW,THICK FILM R-418-1K
R488,R489,R492,R493,R494,R499,R50
0 RES,10K,.1%,.125W THIN FILM R-456-10K
R491,R691 RES,4,99K,1%,100MW THIN FILM R-438-4.99K
R501,R510,R701,R710,R487,R687 RES,100,1%,100MW,THICK FILM R-418-100
R503,R509,R575,R576 RES,499,1%,100MW,THICK FILM R-418-499
R505,R506,R507,R586,R705,R706 RES,.2,1%,30W R-463-.2
R514,R583 RES,2.49K,.1%,.125MW THIN FILM R-456-2.49K
R517,R519 RES,24.9K,1%,100MW,THICK FILM R-418-24.9K
R526 RES,80.6K,1%,100MW THICK FILM R-418-80.6K
R529,R729 RES,3.32K,1%,100MW,THICK FILM R-418-3.32K
R530,R730 RES,237,1%,100MW THICK FILM R-418-237
R533,R524,R617,R733,R798,R799 RES,10M,1%,125MW,THICK FILM R-418-10M
R535,R714,R672,R793,R715,R763,R76
5,
R767
RES,10K,1%,100MW,THICK FILM R-418-10K
R537,R737 RES,16.9K,1%,.1W THICK FILM R-418-16.9K
R538,R738 RES,59K,1%,100MW THICK FILM R-418-59K
Table 16-7
Model 2306-VS analog board parts list (cont.)
Circuit designation Description Keithley part no.
