Keithley 2306 User Manual

16-28 Replaceable Parts
R539,R739,R551,R630 RES,40.2K,1%,100MW,THICK FILM R-418-40.2K
R540,R740 RES,40.2K,1%,100MW,THICK FILM R-418-40.2K
R542,R742 RES,6.19K,1%,100MW,THICK FILM R-418-6.19K
R544,R579,R655,R744 RES,6.04K,1%,100MW THICK FILM R-418-6.04K
R548,R748 RES,.015,1.5W,1% R-468-.015
R552 RES,274,1%,.1W THIN FILM R-438-274
R553 RES,2.49K,1%,.1W THIN FILM R-438-2.49K
R554 RES,24.9K,1%,100MW,THIN FILM R-438-24.9K
R555 RES,392.1%,100MW,THICK FILM R-418-392
R557,R543,R743 RES,2K,1%,100MW,THICK FILM R-418-2K
R559,R564 RES,475,1%,100MW,THICK FILM R-418-475
R565,R568,R566,R605,R614,R663,
R716-R720
RES,10K,1%,100MW,THICK FILM R-418-10K
R571,R572 RES,10K,5%,125MW,METAL FILM R-375-10K
R573 RES,200,1%,100MW,THICK FILM R-418-200
R574 RES,1.87K,1%,.1W,THICK FILM R-418-1.87K
R578,R656 RES,4.02K,1%,100MW,THICK FILM R-418-4.02K
R584,R585 RES,4.99K,.1%,.125W THIN FILM
R-456-4.99K
R589,R654,R795,R797 RES,.0499,1%,100MW,THICK FILM R-418-.0499
R590,R756 RES,2.43K,1%,.1W THICK FILM R-418-2.43K
R591,R755 RES,316K,1%,100MW THICK FILM R-418-316K
R594,R669,R657,R783,R789,R777,R77
8 RES,4.99K,1%,100MW,THICK FILM R-418-4.99K
R643,R712,R417,R556,R593,R651,R75
8,
R528
RES,10K,1%,100MW,THICK FILM R-418-10K
R649,R727,R728,R749,R760,R773 RES,1K,1%,100MW,THICK FILM R-418-1K
R658,R668,R775,R776,R782,R511,R71
1,
R652
RES,10K,1%,100MW,THICK FILM R-418-10K
R665,R791,R792 RES,4.99K,.1%,.1W THIN FILM R-491-4.99K
R666,R592,R757 RES,.0499,1%,100MW,THICK FILM R-418-.0499
R682 RES,4.02M,1%,100MW THICK FILM
R-418-4.02M
R697,R698,R741,R541,R607 RES,1K,1%,100MW,THICK FILM R-418-1K
R700 RES,10K,.1%,.125W THIN FILM (0806) R-456-10K
R703,R709 RES,499,1%,100MW,THICK FILM R-418-499
R707 RES,.1,1%,30W R-463-.1
R713,R736 RES,4.02K,1%,100MW,THICK FILM R-418-4.02K
R722,R725,R726,R563,R482,R525,R56
1,
R567
RES,10K,1%,100MW,THICK FILM R-418-10K
Table 16-7
Model 2306-VS analog board parts list (cont.)
Circuit designation Description Keithley part no.
